| Model | L10Q | L18Q | L210Q | L118Q |
| Frequency response | 70Hz-19KHz(-6dB) | 40Hztocut(-6dB) | 65Hz-19KHz(-6dB) | 40Hztocut(-6dB) |
|
Sensitivity
(1w@1m) |
96dB | 98dB | 97dB | 98dB |
| Rated impedance | 12ohms | 8ohms | 8ohms | 8ohms |
|
Maximum SPL(1m) |
125dB | 128dB | 128dB | 128dB |
| rated power | 300W | 600W | 600W | 600W |
| crossover point | 1.7KHz | / | 1.6KHz | / |
|
Coverage Pattern |
100°x10°(HxV) | / | 100°x10°(HxV) | / |
| Dimensions (H x W x T) | 280mmx550mmx355mm | 600x550x730mm | 280mmx800mmx355mm | 600mmx800mmx600mm |
| Net Weight | 22Kg | 40Kg | 30Kg | 40Kg |
| LF speaker | 1x10" 65 core 170 magnetic | 1x18"100 core 220 magnetic | 2x10" 65 core 170 magnetic | 1x18"100 core 220 magnetic |
| HF speaker | 1x1.5" 75 core 170 magnetic | / | 1x1.5" 75 core 170 magnetic | / |
| input connectors | 2xNL4 | 2xNL4 | 2xNL4 | 2xNL4 |
| Enclosure constructio | 15mm plywood | 18mm plywood | 15mm plywood | 18mm plywood |
