| Model | M06 | M08 | M10 | M12 |
| Frequency response | 90Hz-18KHz(-6dB) | 80Hz-16KHz(-6dB) | 70Hz-16KHz(-6dB) | 60Hz-18KHz(-6dB) |
|
Sensitivity
(1w@1m) |
94dB | 94dB | 96dB | 96dB |
| Rated impedance | 8ohms | 8ohms | 8ohms | 8ohms |
|
Maximum SPL(1m) |
115dB | 117dB | 121dB | 124dB |
| rated power | 150W | 200W | 300W | 350W |
| crossover point | 2.2KHz | 2KHz | 2KHz | 1.8KHz |
|
Coverage Pattern |
80°x50°(HxV) | 80°×50°(HxV) | 80°×50°(HxV) | 90°x60°(HxV) |
| Dimensions (H x W x T) | 351mmx200mmx180mm | 424mmx240mmx221mm | 520mmx313mmx286mm | 623mmx391mmx357 |
| Net Weight | 7kg | 10kg | 12kg | 18kg |
| LF speaker | 1X6.5"35 core 120 magnetic | 1x8" 51 core 120 magnetic | 1x10" 51 core 140 magnetic | 1x12" 65 core 170 magnetic |
| hHF speaker | 1x1.0"(34 core) | 1x1.0"(34 core) | 1x1.0"(34 core) | 1x1.0"(44 core) |
| input connectors | 2xNL4 | 2xNL4 | 2xNL4 | 2xNL4 |
| Enclosure construction | 12mm MDF | 15mm MDF | 15mm MDF | 15mm MDF |
