| Model | M15 | M215 | S18 | S218 |
| Frequency response | 55Hz-18KHz(-6dB) | 50Hz-18KHz(-6dB) | 40Hztocut(-6dB) | 35Hztocut(-6dB) |
|
Sensitivity
(1w@1m) |
96dB | 99dB | 98dB | 104dB |
| Rated impedance | 8ohms | 4ohms | 8ohms | 4ohms |
|
Maximum SPL(1m) |
125dB | 131dB | 128dB | 137dB |
| rated power | 400W | 1000W | 600W | 1200W |
| crossover point | 2.0KHz | 2.0KHz | / | / |
|
Coverage Pattern |
90°x60°(HxV) | 60°x40°(HxV) | / | / |
| Dimensions (H x W x T) | 733xmmx463mmx440mm | 1155mmx430mmx400mm | 690mmx560mmx595mm | 561mmx1066mmx780mm |
| Net Weight | 21Kg | 39kg | 40Kg | 68kg |
| LF speaker | 1x15" 75 core 190 magnetic | 2x15"75 core 190 magnetic | 1x18"100 core 220 magnetic | 2x18"100 core 220 magnetic |
| HF speaker | 1x1.0"(44 core) | 1x1.5"(75 core) | / | / |
| input connectors | 2xNL4 | 2xNL4 | 2xNL4 | 2xNL4 |
| Enclosure construction | 15mm MDF | 15mm MDF | 18mm MDF | 18mm plywood |
