| Nominal diameter | 24"/610mm |
| Magnet type | Ferrite |
| Impedance | 8Ω |
| AES Power | 3500 W |
| Power rating | 7000 W |
| Sensitivity | 98.6dB |
| Frequency range | 24-1000 Hz |
| Maqnet Size | 330X25mm |
| Voice coil diametel | 152mm/6 inch |
| Coil material | PISV-W |
| Number of layers | 4L(Inside/Outside) |
| X-max | 13.3mm |
| Fs | 24 HZ |
| Qts | 0.14 |
| VAS | 457 L |
| Bl | 60.8 Tm |
| Net Weight | 43 kg/pc |
